Engineering Excellence for Complete Road & Cabin Security
The Crossbeats RoadEye DC04 is an enterprise-grade 3-channel dashcam designed for high-end passenger vehicles, commercial fleets, ride-hailing services, and logistics operators. Combining a 4K UHD front camera powered by the Sony STARVIS 2 IMX675 sensor, a dedicated 1080P IR interior cabin recorder, and a 1080P rear camera, the DC04 delivers complete 360-degree forensic recording day and night.
- Front Sensor
- Sony STARVIS 2 IMX675
- Video Resolution
- 4K + 1080P + 1080P
- Wireless Link
- Wi-Fi 6 + Bluetooth 5.2
- Power Architecture
- Industrial Supercapacitor
- Simultaneous 3-channel recording with Zero-Frame-Drop logic
- Infrared cabin LEDs for full-dark interior passenger monitoring
- Built-in GPS logger for geo-synced speed and trajectory mapping
- Industrial supercapacitor withstands cabin heat exceeding 65 °C
- CE, FCC, RoHS, and BIS certified platforms for global distribution
Enterprise Features
Why Fleet Operators & Sourcing Partners Specify DC04
Built to eliminate liability, safeguard passengers, and withstand extreme operating environments without thermal shutdown.
Infrared Cabin Vision
4x 940nm IR LEDs capture clear monochrome interior footage even in pitch-black conditions.Built-in GPS Tracking
Embeds exact speed, UTC timestamp, and GPS coordinates into video metadata for legal protection.High-Speed Wi-Fi 6
Allows rapid wireless video downloads and OTA firmware upgrades through companion iOS/Android app.Supercapacitor Powered
Eliminates battery swelling risk under intense sun soak and supports smooth emergency file closing.24/7 G-Sensor Parking Mode
Time-lapse and collision detection surveillance protects parked vehicles around the clock. Technical Datasheet
Full Hardware & Firmware Specifications
Complete technical specification parameters for procurement evaluation and compliance verification.
| Product Model | Crossbeats RoadEye DC04 (3-Channel System) |
|---|---|
| Front Camera Optics | Sony STARVIS 2 IMX675 (8MP Sensor, F1.8 Aperture, 150° Wide Angle FOV) |
| Front Resolution | 4K UHD (3840 x 2160P @ 30fps) |
| Cabin Camera Optics | Full HD (1920 x 1080P @ 30fps, 135° FOV) with 4x 940nm Invisible IR Night Vision |
| Rear Camera Optics | Full HD (1920 x 1080P @ 30fps, 140° FOV, IP67 Waterproof Rating) |
| Display Screen | 2.4-inch High-Definition IPS Color Display |
| Video Encoding & Format | H.265 / H.264 High Efficiency Video Coding (MP4 Container) |
| Power Storage System | Industrial Supercapacitor (Operating Temp: -20 °C to +70 °C) |
| Wireless Connectivity | Dual-Band Wi-Fi 6 (5GHz / 2.4GHz) + Bluetooth 5.2 for Rapid Pairing |
| GPS Module | Built-in High-Precision GPS Logger (Geo-Synced Route and Speed Overlay) |
| Sensors & Protection | 3-Axis Variable G-Sensor, Emergency Collision Video Lock, Loop Recording |
| Storage Compatibility | MicroSD Class 10 / U3 / V30, Supports capacities up to 512GB (FAT32/exFAT) |
| Power Supply Input | Type-C USB Input (5V / 2.5A) via 12V-24V Vehicle Hardwire or Aux Adapter |
| Export Certifications | CE, FCC, RoHS, BIS Certified (Compliance documentation available) |
| OEM / ODM Support | Custom housing logos, localized UI/firmware, tailored packaging, custom wire lengths |
Proven Sourcing Platform
Tested for High-Duty Fleet & Global Sourcing
From passenger fleets to logistics chains, RoadEye DC04 is designed for uninterrupted continuous operation under severe environmental stress.
3-CH Simultaneous 4K + 1080P + 1080P capture
70 °C Maximum tested operating temperature
512 GB High-capacity continuous loop storage
CE / FCC Global export compliance ready
Sourcing & Technical FAQ
Frequently Asked Questions for Sourcing Managers
A 3-channel setup eliminates blind spots by capturing forward road conditions, interior cabin interactions, and rear traffic events simultaneously. This provides 360-degree protection, vital for ride-hailing services, driver training verification, and fleet liability defense.
Unlike traditional lithium-ion batteries that risk degradation, swelling, or thermal runaway in hot sun, industrial supercapacitors operate safely in temperatures ranging from -20 °C to +70 °C, ensuring long operational lifespan and safe file saving during sudden power cuts.
Yes. We offer complete B2B customization packages including laser-engraved brand logos, bespoke packaging design, localized companion app builds, custom boot splash screens, and pre-configured camera settings tailored to fleet specifications.
The RoadEye DC04 platform is manufactured under ISO9001 standards and is compliant with CE, FCC, RoHS, and BIS regulatory frameworks. Complete test reports and declaration certificates are available upon buyer qualification.
Specify RoadEye DC04 for Your Procurement Line
Request technical documentation, wholesale pricing, or sample units from our engineering desk.
